What We Have
Quality That Speaks Parts That Perform
We offer a wide range of machining capabilities and industry-focused solutions designed to meet your exact requirements — with quality you can count on.
Turning Centers - 18 no's
|
Make & Model
|
Specification
|
Qty
|
|---|---|---|
|
LMW-LL20T-L10
|
X-350 mm, Z-1100 mm , CHK Dia – Ø305 mm
|
1
|
|
LMW-LSL-3B
|
X-310 mm, Z-300 mm , CHK – Ø250 mm
|
1
|
|
Jyoti-DX 350 -700A
|
X-330 mm, Z-200 mm , CHK – Ø250 mm
|
1
|
|
Pravan’s - Hogger -31 5D
|
X-600 mm, Z-300 mm , CHK – Ø320 mm
|
1
|
|
LMW-LL 20T-L5
|
X-340 mm, Z-400 mm , CHK – Ø250 mm
|
4
|
|
LMW-LX 20T –L3
|
X-320 mm, Z-250 mm , CHK – Ø200 mm
|
1
|
|
JYOTI-DX 200-5B
|
X-330 mm, Z-200 mm , CHK – Ø250 mm
|
1
|
|
P.M.T - Super cut - 6N
|
X-220 mm, Z-340 mm , CHK – Ø165 mm
|
1
|
|
BFW - Vortex BTC-1540
|
X-220 mm, Z-350 mm, CHK– Ø165 mm
|
1
|
|
BFW - Vortex BTC-1540
|
X-220 mm, Z-350 mm, CHK– Ø165 mm
|
2
|
|
BFW Neo plus
|
X-250 mm, Z-350 mm, CHK – Ø200 mm
|
2
|
|
LMW S Turn
|
X-300 mm , Z-350 mm , CHK Dia- Ø 200 mm
|
2
|
|
ACE Super Jobber 500LM
|
X-450 mm, Z-600 mm, Chuck Dia– Ø250 mm
|
2
|
|
HMT TSC -20 Double Spindle
|
X-250 mm, Z-400 mm, Chuck Dia– Ø200 mm
|
1
|
Vertical Machining Center - 13 no's
|
Make & Model
|
Specification
|
Qty
|
|---|---|---|
|
Mitubish
|
X-550 mm, Y-415mm, Z-550 mm
|
2
|
|
LMW-JV KRAFT
|
X-800 mm, Y-430mm, Z-500 mm
|
2
|
|
BFW-BMV-35-TC 20
|
X-400 mm, Y-350mm, Z-300 mm
|
1
|
|
LMW –J2 ( Indexer In Build)
|
X -900 mm ,Y-500 mm, Z-600 mm
|
1
|
|
LMW-JV80 ( Indexer In Build)
|
X-1000 mm, Y-550mm, Z-800 mm
|
1
|
|
LMW-JV KRAFT
(4th Axis Inbuild)
|
X-800 mm, Y-430mm, Z-500 mm
|
4
|
|
BFW - Xtron 544 TC24
(4th Axis Inbuild)
|
X-600 mm, Y-400mm, Z-400 mm
|
1
|
|
LMW-J6
(4th Axis Inbuilt)
|
X-1050 mm, Y-600mm, Z-600 mm
|
1
|
Vertical Turning Lathes - 2 no's
|
Make & Model
|
Specification
|
Qty
|
|---|---|---|
|
BFW 800H
|
Turning Dia 900 max, CHK- 630
|
1
|
|
LMW –VTL-LTV40
|
Turning Dia 600 max, CHK-450
|
1
|
FUTURE PLAN:
2025 MACHINE ADDITION PLAN
- VMC - LMW – JV CRAFT - 3 Nos
- LMW TURNING CENTER - 4 Nos
- HMC –BFW-PRIMA 65 PRO - 1 Nos
Horizontal Machining Center- 1 no's
| Make & Model | Specification | Qty | |
|---|---|---|---|
| BFW Prima 55 Pro | Double Pallet Size | 630 X 630 | 1 |
| 60 Tool Magazine | |||
Edm Machine Wirecutting & Sparking
| Make & Model | Specification | Qty |
|---|---|---|
| Cnc wire EDM Machine (SR400S+AL+Z500mm) | Size 500 x 450 | 2 |
| Maximum Machining Weight | 320kg | |
| Machine Description | Specification | Qty |
|---|---|---|
| Zinc die sinking EDM Machine (S-35Z) | Size 500 x 450 | 1 |
| Maximum Machining Weight | 320kg | |
Conventional Machining
We maintain a dedicated line of conventional machines to support custom operations, prototyping, and secondary processes ensuring flexibility and reliability in every stage of production.
| Machine description | Make & Model | Specification | Qty |
|---|---|---|---|
| Conventional Milling –SPM Type | HMT | FN 1 & FN 2 | 10 |
| Conventional Drilling Machines | Eiffco | 1” | 5 |
| Conventional lathe | Rajgot | 12 feet | 2 |
Gear Shapping
| Machine Description | Specification | Qty |
|---|---|---|
| Liebherr L307 | Maximum Diameter Gear Cut 406.4 mm | 1 |
| Maximum Rated D.P. (Module) in Steel 2-8 D.P | ||
| Maximum Axial Travel 304.8 mm | ||
| Work Table and Spindle | ||
| Diameter of Work Table 306.4 mm | ||
| Diameter of Index Worm Wheel 300.05 mm | ||
| Diameter of Center Bore in Work Table 101.6 mm | ||
Horizontal Broach Machine
| Machine Description | Specification | Qty |
|---|---|---|
| HMT Horizontal Broach Machine | Type Splines, keyways, and holes | 1 |
| Diameter Up to 300 mm | ||
| Stroke Length 1500 mm | ||
| Pulling Force 16 Tons | ||
| Power Cylinder Hydraulically Operated | ||
| Cutting Speed Max 15-30 FPM |
Precision Starts with a Conversation
Quality
Assurance
We are committed to delivering excellence by maintaining strict quality control at every stage of production, ensuring every component meets the highest standards of precision and reliability.
Our Commitment
Quality Assurance
We follow stringent quality assurance practices at every stage of production, using advanced inspection tools and processes to ensure every component meets the highest standards of precision and reliability.
Laboratory Equipment
CMM : CONTURA 9/18/8 RDS with VAST XXT TL3 Probe system
Measuring Range
X=900mm, Y=1800mm, Z=800mm
Accuracy
0.0001
Precision In Every Measurement
Monitoring & Measuring Resource Available
| S.No | Instrument name | Range | Least Count | Make | Qty |
|---|---|---|---|---|---|
| 01 | External Micrometers | 0 - 750 (All Ranges) |
0.01 | Mitutoyo & Insize | 10 |
| 02 | Digital External Micrometer | 0 - 225 (All Ranges) |
0.001 | Mitutoyo | 06 |
| 03 | 2D Height master | 0-600 | 0.0001 | Trimos | 01 |
| 04 | Air gauge units | - | 0.0001 | Airtronic | 05 |
| 05 | Variants of Bore Gauge stems | 0 - 700 | - | Mitutoyo | 12 |
| 06 | Variants of Digital & Analog Vernier | 0 – 1000 | 0.01 | Mitutoyo & Insize | 06 |
| 07 | Roughness tester | - | - | Zeiss | 01 |
| 08 | Variants of PPG | 1.10-50.0 | - | Zeiss | 01 |
| 09 | Variant of thread plug gauge | M3-M52 1"BSP-5"BSP 1/4 UNC-2 1/4 UNC |
- | Baker | 01 |
| 10 | Variant of thread ring gauge | M3-M52 1"BSP-5"BSP 1/4 UNC-2 1/4 UNC |
- | Baker | 01 |
Calibrated & Certified
All the instruments are calibrated by NABL accredited third party lab.
Critical Process Control
100% carried critical characteristics and maintain CPK 1.66–1.7.
Continuous Improvement
Attribute and variable dimensions are carried out in our regular practice.
How It Work
Managing Partner
Technical
Managing Partner
Operations
Plant Head
Marketing Head
Quality
Manager
Production
Manager
Store / Purchase
Head
Accounts
Head
HR
Manager
ERP
Administrator
Dispatch
Head
Maintenance
HR Assistant
Executive
5S
5SOrganiser
Packing
Transport
PPC Incharge
Shift
Supervisor
NPD
Engineer
VMC/CNC/VTL/HMC
Operator
Conventional
Operator
CMM
Engineer
Inward/Calibration
Engineer
NPD
Inspector
Final
Inspector
Quality Line
Inspector
